Features:
1. High precision, high resolution, quick sampling speed, full-screen display.
2. Adopting high precision torque sensor, with torque direction display.
3. Upper and lower limit value setting, red and green indicating lights and buzzer audible and visual alarm.
4. Three units can be switched each other (N·m、kgf·cm、lb·in).
5. Real-time, peak, automatic peak three models of optional switch.
6. Use USB interface and PC communications, synchronous test function can connect to the computer, computer synchronous display test force graph and the detailed test process, can save, doing all sorts of analysis.
7. Peak holding, remove automatically function, remove time to set freely.
8. Large storage, can save 99 groups of test data.
9. Without automatic shutdown function, time can be set freely.
Specifications:
1111MicrosoftInternetExplorer402DocumentNotSpecified7.8 磅Normal0
1111MicrosoftInternetExplorer402DocumentNotSpecified7.8 磅Normal0
1111MicrosoftInternetExplorer402DocumentNotSpecified7.8 磅Normal0
| Type Index | No printer | ST-1B | ST-2B | ST-3B | ST-5B | ST-10B | ST-20B | Measuring range / Division value | N·m | 1.0000/0.0001 | 2.0000/0.0001 | 3.0000/0.0001 | 5.0000/0.0001 | 10.000/0.001 | 20.000/0.001 | Kgf·cm | 10.200/0.001 | 20.400/0.001 | 30.600/0.001 | 51.000/0.001 | 102.00/0.01 | 204.00/0.01 | lb·in | 8.850/0.001 | 17.700/0.001 | 26.550/0.001 | 44.250/0.001 | 88.50/0.01 | 177.00/0.01 | Precision | ±0.5% | Peak Value Sampling Frequency | 2000HZ | Power | 8.4V 1.2VX7 Ni-MH Battery group | Charging Time | 4～6 Hours | Continuous using time of battery | About 10 Hours | Battery life | ≥300 times | Size | 400mm×200mm×200mm | Net Weight | 34KG | Power adapter | Input：AC 110V 50HZ Output：DC 10V 300mA
Package included:
1 x Torque tester 4 x Column glue chuck 1 x Charger 1 x USB data cable 1 x Mating software CDS 1 x User manual NOTE:The voltage used by the product is 110V. If the voltage used in your country is not 110V, please purchase carefully, you may not be able to use the product! ! ! <p class="MsoNormal" style="margin-left:21.2500pt;text-indent:-21.2500pt;mso-list:l1 level1 lfo2;
|
